Product Description

The DB9 Male Solder Connector is a heavy-duty, professional-grade interface connector engineered for serial communication cables, industrial machinery data lines, microcontroller programming interfaces, and custom legacy hardware connections. Featuring gold-plated or tin-plated solid pin contacts housed inside a durable shielding shell, this male connector ensures secure signal transmission and robust mechanical stability.

The solder-cup terminals allow you to wire custom pinout configurations effortlessly, making it ideal for RS-232 serial links, custom adapter cables, industrial automation controls, and legacy port repairs.

⚠️ Wiring Tip: Slide your cable’s outer insulation back and slip the heat shrink tubing or metal backshell hood onto the cable before soldering the individual wires to the solder cups. Use a fine-tip soldering iron quickly to avoid melting the plastic insert block.

Technical & Architectural Highlights

• Standard 9-Pin Layout (DB9 Male): Industry-standard D-Sub configuration compatible with standard serial ports and matching female connectors.

• Solder-Cup Terminals: Deep cup design makes wire insertion and soldering secure and reliable.

• Durable Metallic Shielding Shell: Provides EMI/RFI noise reduction and mechanical protection for robust environments.

• Precision Pin Alignment: Ensures smooth mating and secure electrical connection with female DB9 ports.

🧰 Recommended Connectors & Wiring Accessories

Completing your cable assembly or wiring harness? Add these matching connectors and wire management essentials to your order:

1. DB9 Female Solder Connectors: Matching female socket connectors for building custom serial and data cables: Pro Tronix DB9 Connectors Collection

2. D-Sub Plastic & Metal Hoods (Backshells): Protective covers and strain-relief housings for DB9 connectors: Pro Tronix D-Sub Hoods Collection

3. Heat Shrink Tubing Kits: Essential adhesive-lined tubing for insulating soldered pin connections and cable splices: Pro Tronix Heat Shrink Collection

4. Twist-On Wire Connectors (Wire Nuts): Quick, solderless wire splicing connectors for organizing low-voltage panel wiring: Pro Tronix Wire Nuts Collection

5. Jumper Wires & Cables: High-quality copper wire rolls and pre-terminated leads for wiring harnesses: Pro Tronix Wires & Cables Collection

Technical Specifications

Applications

• Serial Communication Cables: Building custom RS-232, RS-485, and serial debugging cables.

• Industrial Automation: Interfacing with PLCs, CNC controllers, and legacy machinery ports.

• Custom Electronics Prototyping: Creating robust multi-wire peripheral connection ports for custom enclosures.

What’s in the Box

• 1 x DB9 Male Solder Connector.
