Product Description
The Male DC Power Socket Jack Prewired is a ready-to-use power output connector designed for quick integration into DIY electronics, LED lighting setups, CCTV camera wiring, and custom power extension cables. Pre-soldered with flexible wire leads, this standard 5.5mm x 2.1mm barrel plug eliminates the need for delicate soldering directly onto terminal pins, allowing for fast, secure connections.
Essential for wiring power supplies to custom devices, extending DC power lines, and interfacing with LED strips or battery packs, this prewired DC male connector combines convenience with reliable power transmission.
⚠️ Wiring & Polarity Tip: Always verify your circuit polarity (typically center-positive) before connecting your power source. Use heat shrink tubing or electrical tape to insulate spliced wire connections and prevent accidental short circuits.
Technical & Architectural Highlights
Prewired Convenience: Comes equipped with factory-soldered wire leads, saving time and eliminating the need for terminal soldering during wiring.
Standard 5.5 x 2.1mm Size: Universally compatible with standard female DC barrel jacks, power adapters, CCTV outputs, and splitter cables.
Color-Coded Leads: Features pre-stripped red (positive) and black (negative) wires for straightforward circuit identification and connection.
Flexible Application: Ideal for custom cable assemblies, battery output adapters, and quick-disconnect power lines.
Technical Specifications
| Parameter | Value / Specification |
| Product Type | Prewired Male DC Power Plug / Barrel Connector |
| Compatible Jack Size | 5.5 mm Outer Diameter x 2.1 mm Inner Diameter |
| Wire Length | Approx. 10cm – 15cm (Color-coded Red / Black) |
| Contact Rating | Typically 12VDC / 1A – 2A (Varies by application) |
| Connector Type | Molded Male Barrel Plug with Wire Leads |
Applications
CCTV & Security Systems: Extending or repairing power lines for security cameras and recording gear.
LED Strip & Lighting Projects: Creating custom power adapters and extension harnesses for single-color LED strips.
Custom Power Harnesses: Connecting battery holders, solar panels, or power supplies to breadboards and custom enclosures.
What’s in the Box
1 x Male DC Power Plug Jack (Prewired with leads).
