Product Description

The HXW 6F22 is a high-performance, rechargeable lithium-based 9V block battery engineered to replace standard disposable alkaline and zinc-carbon cells. Unlike traditional primary 9V batteries that suffer from rapid voltage drops, this lithium cell maintains a highly stable voltage discharge curve, providing consistent power to delicate electronics throughout its cycle. Built with an internal micro-protection circuit, it safeguards your hardware against overcharging, over-discharging, and short-circuits. For field technicians, hardware developers, and electronics hobbyists, it represents an eco-friendly, cost-effective upgrade that dramatically reduces waste while ensuring reliable mobile power for high-drain test gear and prototyping layouts.

Pinout / Layout Connections

This block battery features the standard, industry-standard dual-snap terminal configuration:

• Circular Miniature Terminal (-): The smaller, male snap connector functions as the negative terminal.

• Hexagonal Large Terminal (+): The larger, female snap connector functions as the positive terminal.

• Internal BMS Protection: A built-in micro-printed circuit board is embedded beneath the outer casing to regulate voltage limits and isolate the internal lithium cells during operation or charging.

Applications

• Digital Multimeters & Testers: Reliable, long-lasting power for standard handheld multimeters, network cable testers, and clamp meters.

• Wireless Transmitters & Audio: Powering wireless clip-on microphones, acoustic guitar preamps, and portable guitar effects pedals.

• Smoke Alarms & Security: High-reliability backup power for wireless indoor security systems and diagnostic sensor modules.

• Microcontroller Prototyping: Providing continuous mobile juice to standalone Arduino configurations via a 9V battery snap adapter.
