SSR-40DD Solid State Relay | 3V-32V DC to 5V-200V DC | 40A

SSR-40DD Solid State Relay | 3V-32V DC to 5V-200V DC | 40A

Product Overview

The SSR-40DD from Pro Tronix is a specialized relay built for Direct Current (DC) switching. While most standard SSRs are designed for AC loads, the 40DD model utilizes high-power MOSFET technology to toggle DC circuits between 5V and 200V DC.

This is an essential component for projects where a low-power microcontroller (like an Arduino or ESP32) needs to control a high-current DC device. Because it has no mechanical contacts, it eliminates the “arcing” often seen when breaking high-current DC circuits, making it significantly safer and longer-lasting than traditional electromagnetic relays.

Technical Specifications

Key Features

• DC-to-DC Specialization: Designed specifically for DC loads, preventing the “latching” issues that occur when using AC SSRs in DC circuits.

• Ultra-Fast Response: With switching times under 1ms, it is perfect for high-speed PWM applications like motor speed control or dimming high-power LED arrays.

• Maintenance-Free: No moving parts means no contact pitting or mechanical failure, even after millions of cycles.

• Safe Isolation: Provides full optical isolation between the sensitive control input and the high-power DC output.

Common Applications

• High-Power DC Motors: Controlling the speed or state of large 12V/24V/48V motors in robotics or EVs.

• Solar & Battery Systems: Switching heavy loads in off-grid solar setups or battery charging stations.

• Hydrogen Generators (HHO): Managing the high-current DC required for electrolysis cells.

• DC Heating Elements: Controlling 12V/24V heating pads or specialized industrial DC heaters.

⚠️ Maintenance Tip: High-current DC switching generates significant heat. A dedicated aluminum heat sink is mandatory for loads above 10A, and thermal paste should be applied between the relay and the sink for maximum efficiency.
