JST XH 2.54mm 4-Pin Male Connector Header | Pro Tronix
2.00 EGP
JST XH 2.54mm 4-pin male connector header for secure PCB wire connections. Perfect for stepper motors, battery balance leads, and electronic peripherals!
| Weight | 0.00 kg |
|---|
In stock
Product Description
The JST XH 2.54mm 4-Pin Male Connector Header is a reliable through-hole mounting connector designed for secure, polarized wire-to-board connections in electronic projects and power circuits. Featuring a standard 2.54mm pitch spacing—matching typical breadboard and header pin spacing—and a robust shrouded housing, it ensures secure mating with matching JST XH female cable assemblies while preventing reverse polarity insertion.
Essential for microcontroller power lines, stepper motor connections, balance charging leads, and peripheral sensor wiring, this header solders cleanly onto printed circuit boards for durable four-conductor electrical connections.
⚠️ Polarity & Pinout Tip: Always verify your circuit’s exact pin assignment (such as power, ground, and data signals) against your mating cable before powering on your devices to prevent accidental short circuits or reverse-voltage damage.
Technical & Architectural Highlights
-
Standard 2.54mm Pitch: Universal pin spacing compatible with standard prototyping layouts and jumper wiring.
-
Polarized Shrouded Design: Plastic housing prevents incorrect mating orientation and provides mechanical stability against vibration.
-
Through-Hole Mounting: Robust PCB solder pins ensure a secure, permanent mechanical bond to your circuit board.
-
Low Contact Resistance: High-conductivity metal alloy pins guarantee reliable current flow for power and signal applications.
Technical Specifications
| Parameter | Value / Specification |
| Connector Series | JST XH Series |
| Pitch Spacing | 2.54 mm |
| Number of Pins | 4 Pins |
| Mounting Type | Through-Hole (PCB Header) |
| Gender | Male Header (Pins) |
| Current Rating | Up to 3A AC/DC (Max) |
| Voltage Rating | 250V AC/DC (Max) |
Applications
-
Stepper Motor Connections: Interfacing 4-wire Nema 17 stepper motors to CNC shields and 3D printer mainboards.
-
Battery Balance Leads: Connecting multi-cell lithium battery packs to chargers and protection boards.
-
4-Pin Sensor & Display Modules: Hooking up I2C, serial, or custom 4-wire peripherals to microcontroller boards.
What’s in the Box
-
10 x JST XH 2.54mm 4-Pin Male Connector Headers (or pack quantity as specified).
All your electronics components, connectors, and prototyping accessories are available with fast shipping across Egypt from Pro Tronix!
Pinout Configuration
The 4-pin header provides direct electrical pathways:
| Pin Designation | Description |
| Pin 1 | Power or Signal Line 1 |
| Pin 2 | Power or Signal Line 2 |
| Pin 3 | Power or Signal Line 3 |
| Pin 4 | Ground or Return Line 4 |
