Product Description

The 12mm Metal Self-Locking Push Switch with LED Ring is a rugged, industrial-grade pushbutton switch designed for control panels, automotive dash modifications, custom electronics enclosures, and industrial machinery interfaces. Featuring a durable stainless-steel or nickel-plated brass body with an IP67 waterproof rating, this switch is built to withstand harsh environments, moisture, dust, and heavy daily use.

Equipped with a self-locking (latching) mechanism—push ON, push again OFF—and an integrated 12V LED indicator ring, it provides clear visual status feedback while delivering reliable switching performance. The included rubber O-ring ensures a watertight seal when panel-mounted.

⚠️ Wiring Tip: Pay close attention to the switch terminal layout before connecting your circuit. The switch features separate terminals for the Common (C), Normally Open (NO), and Normally Closed (NC) contacts, alongside dedicated LED positive (+) and negative (-) pins. Use resistors if operating the 12V LED ring on higher voltage rails.

Technical & Architectural Highlights

• Self-Locking (Latching) Action: Stays engaged in the ON position when pressed, and releases when pressed again.

• IP67 Waterproof & Rugged Metal Shell: Heavy-duty stainless steel housing resists corrosion, dust, and water immersion.

• Integrated LED Indicator Ring: Built-in illuminated ring provides clear visual state feedback in low-light conditions.

• 12mm Panel Mount Cutout: Standard compact mounting size fits easily into metal or plastic project enclosures and control panels.

🧰 Recommended Switches & Panel Hardware

Completing your control panel or enclosure assembly? Add these matching switches and wiring accessories to your order:

1. Pushbutton & Toggle Switches: Explore various sizes, momentary and latching toggle switches for control panels: Pro Tronix Switches Collection

2. DB9 Solder Connectors: Professional D-Sub connectors for building robust serial and data interface ports: Pro Tronix DB9 Connectors Collection

3. D-Sub Plastic & Metal Hoods (Backshells): Protective covers and strain-relief housings for secure cable management: Pro Tronix D-Sub Hoods Collection

4. Heat Shrink Tubing Kits: Essential adhesive-lined tubing for insulating soldered wire connections and terminal pins: Pro Tronix Heat Shrink Collection

5. Jumper Wires & Power Cables: High-quality copper wire rolls and pre-terminated leads for wiring control panels: Pro Tronix Wires & Cables Collection

Technical Specifications

Applications

• Control Panels & Automation: Power switches and mode selectors for industrial machinery and enclosures.

• Automotive & Marine Dashboards: Auxiliary light switches, ignition buttons, and accessory controls.

• Custom Electronics & IoT Enclosures: Sleek, durable power buttons for custom equipment and project boxes.

What’s in the Box

• 1 x 12mm Metal Self-Locking Push Switch with LED Ring.

• 1 x Waterproof Rubber O-ring.

• 1 x Mounting Hex Nut.
